High Torsional Stiffness Flexible Disc Coupling Power Transmission Parts For Centrifugal

  • 1
  • 2

Brand Name : REIJAY

Model Number : RB

Certification : Provide

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 500 sets per month

Delivery Time : Negotiable

Packaging Details : Yes

KEY WORDS : Power Transmission Parts

Advantages : High torsional stiffness and no back clearance

Application : Centrifugal

certification : ISO9001/ITS16949

warranty : 2 years

Product name : Flywheel coupling

Installation : video guide

Material : rubber and steel

Feature : High temperature resistance

Customizable : Support

Contact Now

High torsional stiffness and no back clearance Flexible Disc Coupling Power Transmission Parts for Centrifugal

The Flexible Disc Coupling Power Transmission Parts uses disc-shaped flexible elements to accommodate misalignment. Therefore, there are no moving parts and lubrication is not required. This allows years of service without routine maintenance. Floppy disk couplings have other significant advantages. It has high torsional stiffness, no back clearance and low bending stiffness. Provide precise connection at low axle load on connected equipment. The flexible disc coupling also has excellent high-speed performance.


A unique design feature of Flexible Disc Coupling Power Transmission Parts is that it has a combined disc set. This means that all discs and bushings in the package are pre assembled and will not separate. No loose parts can be groped during assembly. Flexible disc couplings are very suitable for remote areas because routine maintenance of lubricated couplings can be a problem. It can also be placed where high ambient temperature will cause problems in coupling with non-metallic components.

We have been Rexroth,Parker,Eaton...supplier for many years. Shanghai Reijay Hydraulic Transmission Technology Co. Ltd. was established in 2003. We are committed to providing the most advanced mechanical transmission components, hydraulic group accessories and heat exchange products (heaters and coolers).

To better satisfy special demands from customers, we can provide non-standard design, product invention, shafting torsional vibration calculation, simulation system testing and related professional software support. More than 40% of the employees in Reijay nowadays are professional engineers (including senior engineers) with bachelor’s degrees or above. At the same time, we are glad to have 8 senior product application engineers and development engineers (including a PhD in Machinery who studied in Germany before). Reijay has established cooperation with many well-known universities and research institutes in dynamic simulation analysis, motion, shock, dynamics, vibration, strength, and other reliability tests. Furthermore, Reijay also cooperates with some research institutes enterprises in development partnerships and industrial and mining application tests.

Technical Specifications

Size Bolt Mounting Center Circke D1(mm) Outer Diameter D(mm) Bolt Hole Diameter Quantity (mm) Location Dimension
96 50 96 4x8 70
125 100 125 3x8 80
135 100 135 3x8 135
150 130 150 5x8 106
152 122 152 3x12 105
155 125 155 3x12 155
210 185 210 3x10 125
220 165 220 6x10 220
220 185 220 3x12 125
170 140 170 3x14 170
209 165/170 209 6x16/3x16 209
RB Series FL flywheel Coupling Technical Parameter
Size Prebore (mm) Dimension (mm)
min max B D2 L1 L2 L3 L4 L5
42 20 42 65 100 42 35 42 20 13
48 20 48 68 100 50 43 50 20 13
65 25 65 96 132 55 49 55 27 21
65 25 65 96 172 55 46 55 31 22
80 30 80 124 172 55 46 55 30 21
100 38 100 152 265 70 78 70 35 21

High Torsional Stiffness Flexible Disc Coupling Power Transmission Parts For Centrifugal

High Torsional Stiffness Flexible Disc Coupling Power Transmission Parts For Centrifugal

High Torsional Stiffness Flexible Disc Coupling Power Transmission Parts For Centrifugal

High Torsional Stiffness Flexible Disc Coupling Power Transmission Parts For Centrifugal

High Torsional Stiffness Flexible Disc Coupling Power Transmission Parts For Centrifugal

Our Strategic Partners

High Torsional Stiffness Flexible Disc Coupling Power Transmission Parts For Centrifugal

Founded in 2003, Shanghai Reijay Hydraulic & Transmission Tech Co., Ltd focus on mechanical power transmission coupling, hydraulic system spare parts and heat exchanger products (oil heating and cooling equipment) manufacture and export. We also provide relevant technical support and service. We also serve customers with the design, assembly, remoulding and maintenance of industrial automation components (pneumatic, hydraulic, PLC), industrial intelligent systems, hydraulic power units and drive sections.

FAQ

Q: Who are we?

We are based in Shanghai, China, started in 2003, sell to Domestic Market(50.00%), North America(25.00%), Europe(5.00%), Africa(5.00%), Southeast Asia(5.00%), South America(5.00%)... There are about 180-300 people in our office and factory.

Q: How can we guarantee quality?

Always a pre-production sample before mass production; Always final Inspection before shipment

Q: What information should I tell you to confirm the product?
Motor drawing or other technique parameters

Q: What can you buy from us?

Couplings, Bellhousings, Oil tanks, Cleaning Covers, Coolers, Hydraulic parts, etc.

Q: Why should you buy from us, not from other suppliers?

We are a professional OEM manufacturer with 20 years of history, focusing on mechanical power transmission coupling, hydraulic system spare parts and heat exchanger product manufacture and export. We also provide relevant technical support and service.

Q: What is your product warranty period?
We offer 2-10 years of service life since the vessel departure date left China.

Q: What are your terms of payment?
Payment≤ 1000 USD, 100% in advance. Payment≥ 1000 USD, 30% T/T in advance, balance before shipment. We accept the LC, also.

Q: What services can we provide?
